| Designation | Value | Unit: metric (US) |
|---|---|---|
| Weight | 1.3 (2.9) | kg (lbs) |
| Inlet Pressure Maximum | 40 (579.7) | bar (psi) |
| Outlet Pressure - Regulated Range | 0.5 (7.2) - 4 (58) | bar |
| Max Working Temperature | 50 (122) | °C |
| Height | 8.5 (3.3) | cm (in) |
| Diameter (Small Passage) | 0.5 (0.2) | cm (in) |
| Diameter (Large Passage) | 0.9 (0.4) | cm (in) |
| Wetted Shares: Stainless Steel, PTFE, Carbide | ♦ | |
| Product Minimum Flow Rate (in a wide passage) | 0.2 (0.1) | l/mn (gal/mn) |
| Product Maximum Flow Rate (in a wide passage) | 1.5 (0.4) | l/mn (gal/mn) |
| ATEX Certification | ATEX/UKCA II 2G Ex h IIB T6 Gb X |
| Designation | SST ball | Pressure gauge | Fluid inlet | Fluid outlet | Part number |
|---|---|---|---|---|---|
| 40-05/4 L.P REGULATOR SMALL FLUID PASSAGE | Ø 5 | - | F 1/4 NPS | F 1/4 BSP (x2) | 155610200 |
| MANUAL REGULATOR 40-0,5/4 SP WITH GAUGE | Ø 5 | ♦ | F 1/4 NPS | F 1/4 BSP (x2) | 155610209 |
| FLUID REGULATOR LP 40 0.5/4 BP | Ø 9 | - | M 1/4 BSP | F 1/4 BSP (x2) | 155610250 |
| MANUAL LP REGULATOR 40-0,5/4 BP WITHGAUGE | Ø 9 | ♦ | M 1/4 BSP | F 1/4 BSP (x2) | 155610259 |
| Designation | Details | Part number |
|---|---|---|
| GAUGE PACKAGE | Spare gauge to check the pressure | 155610570 |
| SUPPORT FOR REGULATOR | Bracket to fix the regulator | 155610576 |
| Designation | Details | Part number |
|---|---|---|
| REPAIRING PACK FR LP FLUID REGULATOR | Pack of spare parts (piston + bearing) | 155610110 |
| SERVICING KIT FR LP REG. SP FOR FLUID PROD.MANUAL CONTROL | Maintenance pack for small passage | 155610111 |
| SERVICING KIT FR LP REG.LARGE PASSAGE FOR FLUID PROD. MANUAL | Maintenance pack for large passage | 155610112 |
