| Designation | Value | Unit: metric (US) |
|---|---|---|
| Maximum Fluid Outlet | 130 (4.6) | cc/min (oz/min) |
| Minimum Fluid Outlet | 68 (2.4) | cc/min (oz/min) |
| Maximum Air Pressure | 6 (87) | bar (psi) |
| Recommended Air Pressure (min) | 2 (29) | bar (psi) |
| Air Consumption | 7.5 (4.4) | m3/h (cfm) |
| Maximum Fluid Temperature | 50 (122) | °C (°F) |
| Air Inlet | M 1/4" NPS | |
| Polished Forged Aluminum Body | ♦ | |
| Wetted Parts, Stainless Steel | ♦ | |
| Ph | 5 - 8 | |
| Weight | 515 (18.2) | g (oz) |
| Designation | Max Fluid viscosity (CA 4) | Aircap | Nozzle size | Needle | Compatibility | Air Consumption | Fluid Output | Fan width at 20cm (8in) | Part number | |
|---|---|---|---|---|---|---|---|---|---|---|
| PROJECTOR | 14 - 20 s | ESG K HVLP | 0.8 mm (0.031 in) | 0.8 | - | 7.5 m3/h (4.4 cfm) | 68 cc/mn (2.3 oz/mn) | 14 cm (5.5 in) | 1 | 031150012 |
| PROJECTOR | 14 - 20 s | ESG K HVLP | 1.0 mm (0.039 in) | 1 | - | 7.5 m3/h (4.4 cfm) | 100 cc/mn (3.4 oz/mn) | 21 cm (8.3 in) | 2 | 031150013 |
| PROJECTOR | 20 - 30 s | ESG K HVLP | 1.2 mm (0.047 in) | 1.2 | - | 7.5 m3/h (4.4 cfm) | 130 cc/mn (4.4 oz/mn) | 24 cm (9.4 in) | 3 | 031150014 |
| AIRCAP | - | ESG K HVLP | - | - | - | - | - | - | 4 | 132150200 |
| Designation | Details | Part number | |
|---|---|---|---|
| PACKAGE OF SEALS S3 GUN | Pack of seals | 2 | 129150901 |
| SERVICING KIT S3 GUN | Maintenance pack (includes a pack of seals + gun components) | 3 | 129150902 |
| PLASTIC GRAVITY O25L CUP FOR J4-J5 | Spare white 0.25L cup with strainer | 4 | 139280200 |
| 0.25L GREY GRAVITY CUP | Spare grey 0.25L cup with strainer for PU and precatalysed fluids | 5 | 139280250 |
| 5 NON-DROP PACKET | Pack of 5 non drop plugs | 6 | 139270210 |
| 5 SCREENS PACKET FOR 0,6L CUP (200µ) | Pack of 5 strainers to put in the cup | 7 | 139270220 |
